2 500,00 €
→ Required for the AI Copilot voice commands and ATC AI-assistant
→ NVIDIA Jetson Orin Nano 8GB inside. See hardware & specs
The brain behind your AI Copilot. Ask in plain language and get answers from your aircraft’s live data. It prepares cockpit actions like frequencies, squawks and waypoints, and each one runs only after you CONFIRM.
Hears ATC with you. Connect your VHF audio and it picks out incoming ATC calls for the ATC AI-assistant.
Serious compute, almost no penalty. 350 g, 7.2 W at idle. It shares a mounting footprint with the EMS, Datahub and AHRS, so you can stack it on the same base plate.
Requires the Ethernet Switch. Pairs with the Datahub for voice control of radio and transponder. See the AI Copilot in action →
| Technical data | |
|---|---|
| Dimensions (W × H × D) | 172 × 39 × 97 (1105) mm |
| Weight | 350 g |
| Power supply voltage | 9 – 28 V DC |
| Power consumption (idle) | 7.2 W |
| Power consumption (max) | 20 W |
| Power consumption (2absolute max) | 45 W |
| Current draw (idle) | 0.6 A (3@12 V) |
| Current draw (max) | 1.7 A (3@12 V) |
| Current draw (2absolute max) | 5 A (3@9 V) |
| Temperature range | −20 °C to +60 °C |
1 Depth including connectors
2 Short-duration peak current/power during worst-case heavy load conditions
3 At nominal supply voltage
