Connection of the control stick, the remote control of the transponder, and the VHF radio over RS-232
| Technical data | |
|---|---|
| Dimensions (W × H × D) | 172 × 31 × 98 (1106) mm |
| Weight | 250 g |
| Power supply voltage | 10 – 40 V DC |
| Power consumption (typical) | 2.4 W |
| Current draw (typical) | 0.2 A at 12 V nominal |
| Temperature range | −20 °C to +60 °C |
| Interface | CAN-BUS |
1 Depth including connectors
